12
5. Secure with tape so that the string pulls from
the front end of the plug
. Taper the tape to
avoid hang-ups inside the wing.
6. Pull servo extension through wing and pro-
vided exit holes in wing panel.
7. Install servo in servo well with the output arm
toward the leading edge of the wing. Drill
holes for servo mounting screws.
8. Install servo with servo mounting screws. Re-
peat servo installation process for all aileron
servos.
