41
9. Tighten cabane mounting bolts
10. Pull aileron extension through pre made hole in
radio floor of fuse.
11. Secure front cabanes using 4-40 x 15mm bolts,
flat washers and blue Loctite
12. Gather the outer struts and mounting hardware.
(8) Steel “L” mounting brackets
(8) 4-40 x 15mm bolts
(8) #6 flat washers
(8) 4-40 lock nuts
(8) 4-40 x 10mm bolts
(8) #6 flat washers
