11 / 34
Do not forget to insert the network connector back into the plug before close the
cover plate.
Close the cover plate and tighten the waterproof connector (C&D) and the screws.
5.3 Connection to the PV Generator (DC)
CAUTION!
Load Disconnection Unit
On the DC side out of inverter there is a circuit breaker (optional), in order that the
inverter can be safely installed, the circuit breaker must be switched off.
