Color Description Functions
Target/focus item
The primary component in the step is this color.
Primary component, decal location,
component location
Connectors, fasteners
All components that attach the primary component
to a different component are this color.
Fasteners, electrical connectors
Primary alternative
If there are 2 primary components in the illustration,
1 of the 2 components is this color.
Secondary component
Secondary alternative
If there are 3 primary components in the illustration,
1 of the 3 components is this color.
Tertiary component
Special tool
Where the special tools or equipment are in an
illustration, they are this color.
Pressure gauges, specified tools
Parts that you move
A component that you must move, and that is not
necessary to remove from the machine.
Electrical wires, hydraulic hoses
Sections
Where a cross-section of a component is necessary,
this color shows the component that you see
through.
Engines, drivetrain
1 General
