AGCO SimplEbale - 4.1 Electrical component list

4.1 Electrical component list
Symbol Name DIN Number Function Location [CAB…A1] A1 CONTROL MONITOR CAB [HNA…A26] A26 Flasher Module HNA [SSC…B04] B04 GEARBOX RPM SSC [PSC…B04] B04 GEARBOX RPM PSC [SSC…B07] B07 DENSITY PRESSURE SSC [PSC…B07] B07 DENSITY PRESSURE PSC [SSC…B18] B18 BALE LENGTH SSC [PSC…B18] B18 BALE LENGTH PSC [UCH…E03] E03 PU LIGHT UCH [UCH…E05] E05 SERVICE LIGHT UCH [UCH…E17] E17 KNOTTER LIGHT UCH [UCH…E19] E19 NEEDLE LIGHT UCH [UCH…E204] E204 Ladder Light UCH [UCH…E23] E23 FIELD LIGHT LH UCH [UCH…E24] E24 FIELD LIGHT RH UCH [CAB…F1] F1 +12 V Power CAB [SSC…F1] F1 Fan Power SSC [PSC…F1] F1 Fan Power PSC [CAB…F2] F2 Switched Power CAB [SSC…F3] F3 +12V Power SSC [PSC…F3] F3 +12V Power PSC [SSC…F4] F4 Lube Power SSC
4 Diagrams
68 SimplEbale
79037906A
