AGCO SimplEbale Workshop Service Manual

1.6.3.4 Needle carriage diagnostics
False Bale Count
Step Diagnostic Result Action
1 Move the needle carriage
to the home position.
Does the needle carriage
status sense an object
(green dot) on the
Diagnostics screen of
the terminal?
Yes Go to step 2.
No Go to step 3.
2 Put a metal object against
the sensor. Does the lamp
on the rear of the sensor
illuminate?
Yes Position the sensor so the
LED illuminates when the
needle carriage is in the
home position.
No Go to step 4.
3 Does the needle carriage
status show when the
needle carriage is not in
the home position?
Yes Do a check of the sensor
for damage, replace the
sensor if necessary.
No Go to step 5.
4 Do a check of the wiring
harness for damage.
Clean the connections. Is
there a 9 V supply to the
connector that the sensor
connects to?
Yes Refer to your approved
dealer.
No Repair or replace the
wiring harness, or replace
the sensor.
5 Do a check of the
alignment of the sensor.
Does the needle carriage
status on the terminal
show a green dot when
the LED on the sensor
illuminates?
Yes Diagnostics complete.
No Position the sensor so the
needle carriage status on
the terminal shows when
the LED on the rear of the
sensor illuminates.
1.6.3.5 Fan diagnostics
The fan does not turn in the forward direction
Step Diagnostic Result Action
1 Can the PTO speed be
identified?
NOTE: The PTO speed
must be >70% of the
usual baler PTO speed to
set the fan to ON.
Yes Go to step 2.
No See PTO Speed
Diagnostics.
1 General
30 SimplEbale
79037906A
