1.6.2 Scale diagnostics page
Fig. 12
(1) Load sensor module voltage
(2) Load sensor data
(3) Load sensor data
(4) Load sensor data
(5) Load sensor data
(6) Tilt sensor data for X axis
(7) Tilt sensor data for Y axis
(8) Tilt sensor data for Z axis
(9) Load sensor module software version
