Fuses
Fuse Amp Description
F1 25 Fan
F2 10 Accessory power
F3 15 Lamps
F4 7.5 Lubrication pump
F5 7.5 Knotter trip system
F6 3 ECU Accessory power
Relays
Relay Description
K1 Fan direction 1
K2 Fan direction 2
K3 Field lamps
K4 Lubrication pump
K5 Knotter trip system
K6 Service lamp
