34
4454C EN 2013-05-14The user interface
CR 35-X DIGITIZER
In key-operator mode, operation is menu driven. The menu displays the key-
operator functions, the active keys, and the service code.
In operator mode and in key-operator mode, both informational and
warning messages can be displayed. Informational messages are displayed as
black text against a white background; warning messages are displayed in
reverse mode.
The status indicator
The light at the top of the CR 35-X indicates the status of the CR 35-X.
1
Key-operator functions
2
Active keys
3
Service code
Color
Constant/
Flashing
Status Action
Green
Constant
Ready. Proceed.
Flashing
• Busy (treating image
plate).
•Reading identification
data of a cassette.
Wait.
Queue management
Digitizer set-up
Date and Time
Send test image
System info
Install
Save configuration
: quit
: ok
: select
KEY-OPERATOR
MENU
SERVICE XXXXX
2
3
1
