4454C EN 2013-05-14 Reading an emergency image plate
CR 35-X DIGITIZER
Reading an emergency image plate in the
dedicated configuration
In the dedicated configuration, you can digitize unidentified emergency
image plates. The digital image data will be assigned default ID data.
To read an emergency image plate:
1 Check that the CR 35-X is ready for operation:
• The CR 35-X must display the operator main screen with ‘Ready’ status, e.g.:
• The status indicator at the top of the CR 35-X must be green and be lit constantly.
2 Press the appropriate emergency button at the front of the CR 35-X.
The emergency button determines the speed class, i.e. the sensitivity, which will be
used to digitize the image plate.
WARNING: To digitize an emergency image plate, you must press the
Confirm key after you have inserted the cassette (refer to step 4).
Image data transmission to the preview and the image processing
station will be suspended until you have pressed the Confirm key.
Note: The CR 35-X is operational if the status field equals ‘READY’, even if
status messages of the destination are shown (e.g. ‘QS not ready’).
For digitizing images of the trunk.
For digitizing images of the limbs.
QS not ready READY
Status field
