49
2241A EN 20040210
Sending test images
To check the communication between the CR 75.0 and the image processing
station, you can send a test image from the Digitizer to the image processing
station.
To send a predefined test image to a specific image processing station:
1 In the key-operator main menu, select ‘Send test image’ via the Up and Down
keys and confirm.
The CR 75.0 will display the Send test image menu:
# If you do not press a key within 1 minute, the CR 75.0 will exit the key-
operator mode.
2 Select the image processing station to which you want to send the test image
via the Left and Right keys.
3 Confirm your choice.
The CR 75.0 will return to the operator screen.
Queue management
Digitizer set-up
Date and Time
Send test image
System info
Install
Save configuration
Fast preview
: quit
: ok
: select
KEY-OPERATOR
MENU
SERVICE XXXXX
To process.station:
[PPname1]
: quit
: ok
: change
SEND
TEST IMAGE
SERVICE XXXXX
