AGFA DX-M - Page 22

22
2321 E EN 20130722
DX-G/DX-M
6 Insert the locking tool in the round opening in the front cover.
7 Push the tool towards the end and pull tight clockwise by use of the ratchet:
8 Remove the tool. The digitizer is now ready for transport.
Caution: If the digitizer is transported without the transport locks
attached the device can be damaged.
