51
2321 E EN 20130722
DX-G/DX-M
Status Indicator
The indicator informs the user by light signals about the status of the digitizer
(e.g. image plate erasing cycle progress, operational indications such as warm
up,...). It is positioned at the front of the digitizer, so that it is visible from a
distance.
Color Constant/
Flashing
Status Action
Blue Constant Activating the erasure
cycle.
Enter cassettes into the
input buffer for erasing.
Remove cassettes from
the output buffer.
Flashing Proceeding with the era-
sure cycle.
Green Constant Stand-by mode (READY).
Flashing Busy with scanning and
transporting cassette and
image plate.
Enter cassettes into input
buffer for scanning.
Remove cassettes from
output buffer.
Red Constant
•Service mode
•Fatal error
•Check digitizer touch
panel and workstation
display for further infor-
mation and detailed
instructions.
•Contact an Agfa certi-
fied service engineer.
Flashing
•Warm up / Self-test
•Processing Software down
•Error
Check digitizer touch
panel and workstation
display for further infor-
mation and detailed
instructions.
