70
2321 E EN 20130722
DX-G/DX-M
9 Move the digitizer to the desired location.
10 Once on the desired site, turn the screw clockwise until the digitizer is fixed on
the ground and you encounter resistance.
Now the digitizer is ready for operation.
11 Put back the tool.
12 Reconnect all electrical connections.
• Reconnect the ethernet cable.
• Plug the power plug into the socket.
WARNING: Observe great care when moving the digitizer to the
desired location. So please select a path free from inclinations and
thresholds to prevent the digitizer from shocks during movement.
Caution: Operating the digitizer in a not-fixed condition may result in image
artefacts.
