89
2321 E EN 20130722
DX-G/DX-M
This device is intended for operation in the electromagnetic environment
given below. The user of the device should ensure that it is used in such
an environment.
Resistance to
Jamming Test
IEC 60601
Test Level
Level of
Agreement
Electromagnetic Environ-
ment Guidelines
Discharge of
static electricity
in accordance
with IEC 61000-
4-2
+ 6 kV contact
discharge
+ 8 kV air dis-
charge
+ 6 kV contact
discharge
+ 8 kV air dis-
charge
Floors should consist of
wood, concrete or ceramic
tiles. The relative humidity
must be at least 30%, if the
floor is made of synthetic
material.
Fast transient
electrical distur-
bance variables
/ bursts in accor-
dance with IEC
61000-4-4
+ 2 kV for net-
work leads
+ 1 kV for entry
and outlet leads
+ 2 kV for net-
work leads
+ 1 kV for entry
and outlet leads
The quality of the voltage
supplied should correspond
to a typical commercial or
clinical environment.
Impulse volt-
ages (surges) in
accordance with
IEC 61000-4-5
+ 1 kV push-pull
voltage
+ 2 kV common
mode voltage
+ 1 kV push-pull
voltage
+ 2 kV common
mode voltage
The quality of the voltage
supplied should correspond
to that of a typical commer-
cial or clinical environment.
Voltage break-
throughs, short
term interrup-
tions and varia-
tions in the
voltage supplied
in accordance
with IEC 61000-
4-11
•< 5% U
r
(> 95% break-
through of U
r
)
for ½ period
•40% U
r
(> 60%
breakthrough of
U
r
) for 5 periods
•70% U
r
(30%
breakthrough of
U
r
) for 25 peri-
ods
•< 5% U
r
(95%
breakthrough of
U
r
) for 5 s
•< 5% U
r
(> 95% break-
through of U
r
)
for ½ period
•40% U
r
(> 60%
breakthrough of
U
r
) for 5 periods
•70% U
r
(30%
breakthrough of
U
r
) for 25 peri-
ods
•< 5% U
r
(95%
breakthrough of
U
r
) for 5 s
The quality of the voltage
supply should correspond to
that of a typical commercial
or clinical environment.
If the user wants the device
to work continuously, even
when the energy supply is
interrupted, it is recom-
mended to use an energy
supply free of interruptions
or a battery.
Magnetic field at
the supply fre-
quency (50/60
Hz) in accor-
dance with IEC
61000-4-8
3 A/m 3 A/m Magnetic field at the net-
work frequency should cor-
respond to the typical values
as they are in a commercial
and clinical environment.
Note: U
r
is the alternating voltage.
