:ANAPURNA L/XL OPERATOR MANUAL
AB]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]16] 8/09/2006]
6. UV Curing System.
6.1. General information
-
2 UV sources positioned in front of and behind head base plate
- High speed on-the-fly curing
- Curing power: 120 W/cm
- 2 fixed settings: Full and half strength
- Air cooled lamp-house
- Quick and easy replacement of the UV-bulbs
(Always change both the lamps !!)
- Expected lifetime ± 1000 hours
- Use of an automated shutter system
6.2. Curing setup and sequences
- Settings in software:
- Lamps continous ON (lamp stays “ON” for next print; longest lifetime)
- WarmUp Time (when turning back on the UV lamps, before ready state)
- Cooling Time (after turning off the UV lamps)
- Lamp Type: Cure (Default), Set or Both
