2 Getting Started with the Logic Analyzer
30 16800 Series Portable Logic Analyzers Installation/Quick Start Guide
Specifications and Characteristics
The following electrical and operating characteristics are not specifications,
but are typical operating characteristics for the Agilent 16800 Series logic
analyzers.
Electrical Characteristics
Power
Requirements
16801A, 16802A, and 16803A: 115/230 Vac +/- 20%, 48-66Hz, 615W
Max.
16804A, 16806A, 16821A, 16822A, and 16823A: 115/230 Vac +/- 20%,
48-66Hz, 775W Max.
CAT II (Line voltage in appliance and to wall outlet).
Pollution degree 2.
Environmental Characteristics (Operating)
Temperature Instrument: 0° to + 50° C (+32° to +122° F).
Probes/cables: 0° to + 65° C (+32° to +149° F).
Altitude 3,000 m (10,000 ft).
Humidity Relative humidity 8 to 80% at 40° C (104° F). Avoid sudden, extreme
temperature changes which could cause condensation on the circuit
board.
For indoor use only.
