Agilent Technologies 33220A

298
Chapter 5 Error Messages
Execution Errors
5
-222 Data out of range;
large period limits minimum pulse width
For a pulse waveform, the minimum pulse width is 20 ns for periods up
to 10 seconds. For periods above 10 seconds, the minimum pulse width is
greater. See “Pulse Configuration Commands” in chapter 4 for further
information.
-222 Data out of range;
pulse edge time limited by width; value clipped to ...
The specified edge time must fit within the specified pulse width as
shown below. The function generator will adjust the edge time as needed
to accommodate the specified pulse width.
Edge Time <
0.625 X Pulse Width
-222 Data out of range;
pulse edge time limited by duty cycle; value clipped to ...
The specified edge time must fit within the specified pulse duty cycle as
shown below. The function generator will adjust the edge time as needed
to accommodate the specified pulse duty cycle.
Edge Time <
0.625 X Period X Duty Cycle ÷ 100
-222 Data out of range;
period; value clipped to ...
This generic message indicates that the pulse period has been limited to
an upper or lower boundary.
-222 Data out of range;
frequency; value clipped to ...
This generic message indicates that the waveform frequency has been
limited to an upper or lower boundary.
-222 Data out of range;
user frequency; value clipped to upper limit
This generic message indicates that the waveform frequency has been
limited to an upper boundary due to the selection of the arbitrary
waveform function (APPL:USER or FUNC:USER command).
