302
Chapter 5 Error Messages
Execution Errors
5
-222 Data out of range;
duty cycle; value clipped to ...
The square wave duty cycle is limited to values between 20% and 80% by
instrument hardware.
-222 Data out of range;
duty cycle limited by frequency; value clipped to upper limit
The square wave duty cycle is limited to values between 40% and 60%
when the frequency is greater than 10 MHz.
Duty Cycle: 20% to 80% (frequency <
10 MHz)
40% to 60% (frequency > 10 MHz)
-224 Illegal parameter value;
An exact parameter value, from a list of possible values, was expected.
