5
Technical Information
Specifications
64/104 Agilent 4UHV Ion Pump Controller User Manual / 87-900-137-01 (A)
Fuse Holder
The following figure shows the location of this assembly.
Figure 11
Rear Panel
Proceed as follows to replace one or both fuses:
1 Disconnect the mains cable
2 Waiting for 15 second
3 Remove the fuse with a small screwdriver
4 Replace the fuse
5 Use only 5x20 T6.3A 250V fuses
