Agilent Technologies 4UHV User Manual

5
Technical Information
Serial
84/104 Agilent 4UHV Ion Pump Controller User Manual / 87-900-137-01 (A)
Error Description
Controller errors can be displayed in two windows:
 WIN 505 where the user writes the channel whose error is to be
viewed
 WIN 206 where the controller shows the error code of the
channel written in window 505.
If the value 0 is written in window 505, the errors of all the channels
remain displayed in window 206.
Table 9
WIN 505 value Channel
0 All channels
1
Channel 1
2
Channel 2
3
Channel 3
4
Channel 4
Error Code
The error code is displayed in decimal format. Binary representation
of this number provides indications regarding the type of error that
has occurred.
The error table is shown below:
Table 10
Error code in decimal
format
Binary Description
0 0000000000000 No error
1 0000000000001 FAN error
2 0000000000010 Power input error from HV
4 0000000000100 Power input error from PFC
8 0000000001000 Overtemp PFC
16 0000000010000 Error communication CPU-HV
