72/104 Agilent 4UHV Ion Pump Controller User Manual / 87-900-137-01 (A)
+24V
A
Connection of Input remote
In order to activate the inputs remote (CH on/off, Ch protect, CH
Step) connect the pins as following:
Figure 16 Input
Controller
Customer
device’s
