Agilent Technologies 4UHV User Manual

Technical Information
Specifications
5
Agilent 4UHV Ion Pump Controller User Manual / 87-900-137-01 (A) 63/104
Rear Panel Description
Figure 10 Rear Panel
The following are present on the rear panel:
 The HV connectors ( 1, 2, 3 or 4 according to model)
 The interlock connectors associated to each channel
 The fuses
 The DB9 connector for RS232 and RS485 serial communication
 The DB37 connector for Remote I/O signals.
Fuses
Interlock
connector
HV Connectors
Serial
Port
Remote I/O
