Agilent Technologies 4UHV User Manual

5
Technical Information
Serial
86/104 Agilent 4UHV Ion Pump Controller User Manual / 87-900-137-01 (A)
Write 1
02 80 35 30 35 31 30 30 30 30 30 31 03 38 33
STX ADDR WINDOW WR DATA ETX CRC
02 80 06 03 38 35
STX ADDR ACK ETX CRC
Error code (Win 206)
Interlock error:
02 80 32 30 36 30 03 38 37
STX ADDR WINDOW RD ETX CRC
02 80 32 30 36 30 30 30 30 30 33 32 03 38 36
STX ADDR WINDOW WR DATA ETX CRC
Channel selection (Win 505)
Write 2
02 80 35 30 35 31 30 30 30 30 30 32 03 38 30
STX ADDR WINDOW WR DATA ETX CRC
02 80 06 03 38 35
STX ADDR ACK ETX CRC
Error code (Win 206)
Interlock not present error because channel 2 has been selected:
02 80 32 30 36 30 03 38 37
STX ADDR WINDOW RD ETX CRC
02 80 32 30 36 30 30 30 30 30 30 30 03 38 37
STX ADDR WINDOW WR DATA ETX CRC
