Technical Information
Serial
5
Agilent 4UHV Ion Pump Controller User Manual / 87-900-137-01 (A) 89/104
Table 13
No. Description ASCII Hex
1 Local/remote Z0 5Ah 30h
3 HV-ON/OFF A0 41h 30h
4 Device number F0 46h 30h
5 Measurement unit D0 44h 30h
7 Protect C0 43h 30h
8 Fixed/Step B0 42h 30h
9 Power supply polarity G0 47h 30h
10 Max. power J0 4Ah 30h
11 Vmax H0 48h 30h
12 Iprotect K0 4Bh 30h
13 Set point P0 50h 30h
14 V meas. S0 53h 30h
15 I meas. T0 54h 30h
16 P meas. U0 55h 30h
17 Set-point status g0 67h 30h
18 Interlock status ]0 5Dh 30h
19 Error status z0 7Ah 30h
