To pan and zoom a waveform
To pan and zoom a waveform
1Press the Run/Stop key to stop acquisitions. The Run/Stop key is
illuminated red when the oscilloscope is stopped.
2 Turn the sweep speed knob to zoom horizontally and turn the
volts/division knob to zoom vertically.
The ∇ symbol at the top of the display indicates the time reference point where
the zoom-in/zoom-out is referenced.
3 Turn the Delay time knob ( ) to pan horizontally and turn the channel
position knob
( ) to pan vertically.
