Agilent Technologies 54621A - 54620;40-Series Oscilloscope Front Panels

2-7
Front-Panel Overview
54620/40-series Oscilloscope Front Panels
54620/40-series Oscilloscope Front Panels
Figure 2-1
54621A, 54622A, 54641A, and 54642A 2-Channel Oscilloscopes Front Panel
Display
Horizontal
controls
Trigger
controls
Run
controls
Intensity
control
Power
switch
Vertical
inputs/
controls
External
Trigger
input
Probe
comp
output
Floppy
disk
Softkeys
Waveform
keys
Measure
keys
File
keys
Entry
knob
Autoscale
key
Utility
key
