7-11
Performance Characteristics
Agilent 54620-series Performance Characteristics
General Characteristics
Physical:
Size
Weight
32.26 cm wide x 17.27 cm high x 31.75 cm deep (without handle)
6.35 kgs (14 lbs)
Calibrator Output Frequency ~1.2 kHz; Amplitude ~5 V
Trigger Out 0 to 5 V with 50
Ω source impedance; delay ~ 55 ns
Printer Power 7.2 to 9.2 V, 1 A
Kensington lock Connection on rear panel for security
Power Requirements
Line Voltage Range 100 - 240 VAC ±10%, CAT II, automatic selection
Line Frequency 47 to 440 Hz
Power Usage 100 W max
Environmental
Characteristics
Ambient Temperature Operating -10 ° C to +55 ° C
Non-operating -51 ° C to +71 ° C
Humidity Operating 95% RH at 40 ° C for 24 hr
Non-operating 90% RH at 65 ° C for 24 hr
Altitude Operating to 4,570 m (15,000 ft)
Non-operating to 15,244 m (50,000 ft)
Vibration HP/Agilent class B1 and MIL-PRF-28800F Class 3 random
Shock HP/Agilent class B1 and MIL-PRF-28800F (operating 30 g, 1/2 sine, 11-ms duration, 3
shocks/axis along major axis. Total of 18 shocks)
Pollution degree2 Normally only dry non-conductive pollution occurs. Occasionally a temporary
conductivity caused by condensation must be expected.
Indoor use only This instrument is rated for indoor use only
Installation categories
CAT I: Mains isolated
CAT II: Line voltage in appliance and to wall outlet
* Denotes Warranted Specifications, all others are typical. Specifications are valid after a 30-minute warm-up period and
±10 ° C from firmware calibration temperature.
