Agilent 5890 1 Agilent 5890 GC Control Module
1 Agilent 5890 GC Control Module
The Agilent 5890 GC driver can control Agilent (formerly HP) 5890A,
5890 Series II and 4890Dchromatographs.
Fig 1: Agilent (HP) 5890 with an autosampler
Tab 1: Control Board compatibility:
Control Board Status Description
19257-60015 HPIB/RS232
Newer type; working; both analog
outputs supported.
19257-60010 HPIB/RS232
Tested in DataApex. Older type;
working; only one analog output is
supported
19242-60010 INET
commonly used with integrators, cannot
be used
19242-60015 INET
commonly used with integrators,
buffered communication, cannot be
used
19242-60030 RS232
RS232 board only, uses different
communication protocol, cannot be
used
