6 General Maintenance

To Remove the EI HES Filaments

166 5977C GC/MSD Operating Manual

5 Use the hand grip on the filament block to remove the filament block from

the source.

6 Remove the dual filament from the filament block by lifting the source body

up off of the filament block, while holding the filament block so that the dual

filament will not fall and become damaged.

CAUTION

Use extra caution when removing the dual filament, as it is extremely brittle.
