Agilent Technologies 654 A Series Service Manual

102 Replaceable Parts
Table 5-5. Parts List For 200 Watt A1 Main Board for Agilent Models 654xA and 664xA (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
F402 2110-0697 Fuse, subminature 15AM, 32V
F403 2110-0697 Fuse, subminature 15AM, 32V
F415 65/6641A-65/6644A 8159-0005 Resistor Zero Ohms
F417 65/6641A-65/6642A 8159-0005 Resistor Zero Ohms
F451 65/6641A-65/6644A 8159-0005 Resistor Zero Ohms
F452 65/6641A-65/6644A 8159-0005 Resistor Zero Ohms
F600 2110-0699 Fuse, subminature 5AM, 125V
F601 2110-0699 Fuse, subminature 5AM, 125V
F605 65/6642A 8159-0005 Resistor Zero Ohms
F606 65/6642A 8159-0005 Resistor Zero Ohms
F607 65/6642A 8159-0005 Resistor Zero Ohms
F670 65/6642A 8159-0005 Resistor Zero Ohms
F675 2110-0671 Fuse .125AM, 125V
F700 2110-0671 Fuse .125AM, 125V
F701 2110-0671 Fuse .125AM, 125V
F902 65/6642A 8159-0005 Resistor Zero Ohms
J300 1251-4245 Connector 2-PIN M
J401 1251-5339 Connector-UTIL
J450 1251-3837 Connector 4-PIN M
J451 1252-3771 AC LINE MODULE
J452 1252-2105 Connector-UTIL
J501 1251-8184 MOD PHONE RCPT
J600 1251-4246 Connector-POST-TP-HDR
J602 1252-0063 Connector-POST-TP-HDR
J640 1252-3693 Connector
J690 0360-1809 Barrier block
Q201 65/6641A-65/6644A 1854-0989 XSTR NPN SI
Q201 65/6645A 1855-0849 MOSFET-N-CHAN
Q202 65J6641A, 65/6642A 5060-3315 FET Assembly HS (1855-0725)
Q202 65/6643A, 65/6644A 5060-3314 FET Assembly HS (1855-0641)
Q203 65/6641A-65/6644A 1854-0989 XSTR NPN SI
Q203 65/6645A 1855-0849 MOSFET-N-CHAN
Q204 65/6641A, 65/6642A 5060-3315 FET Assembly HS (1855-0725)
Q204 65/6643A, 65/6644A 5060-3314 FET Assembly HS (1855-0641)
Q205 65/6641A-65/6644A 1854-0989 XSTR NPN SI
Q205 65/6645A 1854-1162 XSTR-NPN
Q206 65/6641A, 65/6642A 5060-3231 Regulator Assembly HS ( 1853-0497)
Q206 65/6643A-65/6645A 5060-3250 ASSY-HS REG (1853-0642)
Q207 65/6641A-65/6644A 1854-0989 XSTR NPN SI
Q207 65/6645A 1855-0849 MOSFET-N-CHAN
Q208 65/6641A, 65/6642A 5060-3315 FET Assembly HS (1855-0725)
Q208 65/6643A, 65/6644A 5060-3314 FET Assembly HS (1855-0641)
Q301 65/6641A-65/6644A 1854-0989 XSTR NPN SI
Q301 65/6645A 1855-0849 MOSFET-N-CHAN
Q302 65/6641A, 65/6642A 5060-3315 FET Assembly HS (1855-0725)
Q302 65/6643A, 65/6644A 5060-3314 FET Assembly HS (1855-0641)
