Agilent Technologies 654 A Series Service Manual

Replaceable Parts 103
Table 5-5. Parts List For 200 Watt A1 Main Board for Agilent Models 654xA and 664xA (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
Q303 65/6641A-65/6644A 1854-0989 XSTR NPN SI
Q303 65/6645A 1855-0849 MOSFET-N-CHAN
Q304 65/6641A, 65/6642A 5060-3315 FET Assembly HS (1855-0725)
Q304 65/6643A, 65/6644A 5060-3314 FET Assembly HS (1855-0614)
Q305 65/6641A-65/6644A 1854-0989 XSTR NPN SI
Q305 65/6645A 1855-0849 MOSFET-N-CHAN
Q306 65/6641A, 65/6642A 5060-3315 FET Assembly HS (1855-0725)
Q306 65/6643A, 65/6644A 5060-3314 FET Assembly HS ( 1855-0641)
Q307 65/6641A-65/6644A 1854-0989 XSTR NPN SI
Q307 65/6645A 1855-0849 MOSFET-N-C H A N
Q308 65/6641A, 65/6642A 5060-3315 FET Assembly HS (1855-0725)
Q308 65/6643A, 65/6644A 5060-3314 FET Assembly HS (1855-0614)
Q600 65/6642A 5060-3321 Regulator Assembly HS (1826-0106)
Q601 65/6642A 5060-3320 Regulator Assembly HS (1826-0122)
Q700 1854-0477 XSTR NPN 2N2222A
Q770 5060-3245 Regulator Assembly HS
R201 65/664lA, 65/6642A 0811-3849 Resistor 0.25 5% 3W
R201 65/6643A 0811-3848 Resistor 0.39 5% 3W
R201 65/6644A 0811-3847 Resistor 0.66 1% 3W
R201 65/6645A 0811-1220 Resistor 1.5 5% 3W PW
R202 0698-3430 Resistor 21.5 1%
R203 65/6641A-65/6644A 0698-3441 Resistor 215 1% .125W
R204 0757-0280 Resistor 1K 1% .125W
R206 65/6641A, 65/6642A 0811-3849 Resistor 0.25 5% 3W
R206 65/6643A 0811-3848 Resistor 0.39 5% 3W
R206 65/6644A 0811-3847 Resistor 0.66 1% 3W
R206 65/6645A 0811-1220 Resistor 1.5 5% 3W PW
R207 0698-3430 Resistor 21.5 1%
R208 65/6641A-65/6644A 0698-3441 Resistor 215 1% .125W
R209 0757-0280 Resistor 1K 1% .125W
R210 65/6641A 0698-8959 Resistor 619K 1%
R210 65/6642A 0698-8959 Resistor 619K 1%
R210 65/6643A 0757-0481 Resistor 475K 1%
R210 65/6644A 0757-0481 Resistor 475K 1%
R210 65/6644A 0699-0070 Resistor 3.16M 1%
R211 65/6641A,65/6642A 0811-3849 Resistor 0.25 5% 3W
R211 65/6643A 0811-3848 Resistor 0.39 5% 3W
R211 65/6644A 0811-3847 Resistor 0.66 1% 3W
R211 65/6645A 0811-1220 Resistor 1.5 5% 3W PW
R212 0757-0316 Resistor 42.2 1%
R213 0698-3441 Resistor 215 1% .125W
R214 0698-0085 Resistor 2.61K 1%
R215 65/6641A-65/6643 0698-3454 Resistor 215K 1%
R215 65/6644A, 65/6645A 0757-0466 Resistor 110K 1%
