Replaceable Parts 113
Table 5-5. Parts List For 200 Watt A1 Main Board for Agilent Models 654xA and 664xA (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
U512 1826-1896 IC-Linear
U513 1826-1370 IC 365
U600 5060-3321 Regulator (1826-0126)
U601 5060-3320 Regulator (1826-0122)
U602 5060-3229 Regulator (1826-0214)
U603 65/6641A-65/6644A 1826-1533 IC 34072
U605 1826-2252 IC OP270GP
U606 1826-1878 IC-72
U607 1826-1533 IC 34072
U608 1826-1370 IC 365
U609 1826-1533 IC 34072
U610 1826-1533 IC 34072
U700 1990-0543 Optical isolator
U720 1826-0468 IC MC3423Pl
U721 1858-0047 XSTR ARY 16P-DIP
U740 1858-0076 XSTR ARY 14P-DIP
U741 1858-0077 XSTR ARY 14P DIP
VR510 1902-0958 Diode Zener l0V 5%
VR511 1902-0958 Diode Zener l0V 5%
VR610 65/6642A 1902-0958 Diode Zener l0V 5%
VR611 65/6642A 1902-0958 Diode Zener 10V 5%
VR720 1902-0947 Diode Zener 3.6V 5%
VR721 . 1902-0947 Diode Zener 3.6V 5%
VR770 1902-0955 Diode Zener 7.5V 5%
VR771 1902-0958 Diode Zener l0V 5%
Y501 0410-2109 XTAL 12.000 MHZ
Z610 1902-0958 Diode Zener l0V 5%
Z611 1902-0958 Diode Zener l0V 5%
Z720 1902-0947 Diode Zener 3.6V 5%
Z721 1902-0947 Diode Zener 3.6V 5%
Z770 1902-0955 Diode Zener 7.5V 5%
Z771 1902-0958 Diode Zener l0V 5%
To Next Page
