Agilent Technologies 654 A Series Service Manual

114 Replaceable Parts
Table 5-6. Parts List For 500 Watt 655xA & 665xA Main Chassis
Reference
Desig.
Applicable
Models
Agilent Part
No.
Description
B1 5060-3436 Fan, 4-inch, tubeaxial, 12Vdc
F450 2110-0054 Fuse 15AM, 250V (for 100 Vac line)
F450 2110-0249 Fuse 12AM, 250V (for 120 Vac line)
F450 2110-0614 Fuse 7AM, 250V (for 220/240 Vac line)
T1 65/6651A 9100-4900 Power Transformer
65/6652A 9100-4845 Power Transformer
65/6653A 9100-4848 Power Transformer
65/6654A 9100-4846 Power Transformer
65/6655A 9100-4899 Power Transformer
W1A 06652-80006 AC cable (A1J450/A3S1)
W1B 06652-80007 AC cable (A3S1/T1)
W2 65/6651A 06652-80004 +Rail (T1/A1J404)
65/6652A 06652-80004 +Rail (Tl/A1J401)
65/6653A-65/6655A 06654-80001 +Rail (Tl/A1J411)
W3 65/6651A-65/6653A 06652-80003 Rail (Tl/A1J405)
65/6654A, 65/6655A 06654-80003 Rail (Tl/A1J405)
W4 65/6651A-65/6653A 06652-80005 Center Tap (Tl/A1J403)
65/6654A, 65/6655A Not Used
W5 65/6651A 06652-80005 Center Tap (Tl/A1J402)
65/6652A-65/6655A Not Used
W6 65/6651A 06652-80004 +Rail (Tl/A1J401)
65/6652A 06652-80004 +Rail (Tl/A1J404)
65/6653A, 65/6654A Not used
W7 06652-80009 AC bias (Tl/A1J600)
W8 06652-80008 GPIB bias (Tl/A2P101)
W9 06652-80010 Phone cable (A1J501/A2J107)
W10 06652-80011 Phone cable (A2J108/A3A1J6)
W 11 06652-80010 Phone cable (A1J670/A4A1J201)
W12 06652-80001 +Rail,-Rail, +Out (Al/A4A1J202)
W13 06652-80011 Phone cable (A1J672/A4A2J301)’
W14 06652-80002 +Rail, -Rail, +Out (Al/A4A2J302)
W15 06652-80010 Phone cable (A1J671/A4A3J201)
W16 06652-80001 +Rail, -Rail, +Out (Al/A43J202)
W17 06652-80011 Phone cable (A1J673/A4A4J301)
W18 06652-80002 +Rail, -Rail, +Out (Al/A4A4J302)
Wl9 5080-2261 Ribbon cable (A3A1J2/LCD display)
Al 65/6651A 06651-61020 Main PCB Tested
65/6652A 06652-61020 Main PCB Tested
65/6653A 06653-61020 Main PCB Tested
65/6654A 06654-61020 Main PCB Tested
65/6655A 06655-61020 Main PCB Tested
A2 6551A-6555A 5060-3398 Isolator Board Tested
A2 6651A-6655A 5060-3399 GPIB Board PCA Tested (surface mount, see Table 5-9A)
A2 6651A-6655A 5060-3317 GPIB Board PCA Tested (through-hole, see Table 5-9B)
A3 5060-3400 Front Panel Board Unitialized and Tested
A3 6551A 06551-61001 Front Panel Board Initialized & Tested
A3 6552A 06552-61001 Front Panel Board Initialized & Tested
A3 6553A 06553-61001 Front Panel Board Initialized & Tested
A3 6554A 06554-6100l Front Panel Board Initialized & Tested
