Replaceable Parts 115
Table 5-6. Parts List For 500 Watt 655xA & 665xA Main Chassis (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
A3 6555A 06555-61001 Front Panel Board Initialized & Tested
6551A 06551-80001 Name plate
6552A 06552-80014 Name plate
6553A 06553-80001 Name plate
6554A 06554-80002 Name plate
6555A 06555-80001 Name plate
6651A 06651-8000l Name plate
6652A 06652-80014 Name plate
6653A 06653-8000l Name plate
6654A 06654-80002 Name plate
6655A 06655-8000l Name plate
DSP1 5063-2304 LCD Display
Gl,G2 0960-0912 Optical Encoders (Rotary V and I controls)
5040-1665 Keypad
5063-3407 PCA Keypad
S1 3101-3088 AC line on/off switch
A4 Heat sink assembly
A4AI Top Left Tunnel Board
65/6651A 06651-61022 Left Tunnel Board
65/6652A 06652-61022 Left Tunnel Board
65/6653A 06653-61022 Left Tunnel Board
65/6654A 06654-61002 Left Tunnel Board
65/6655A 06655-61022 Left Tunnel Board
A4A2 Top Right Tunnel Board
65/6651A 06651-61023 Right Tunnel Board
65/6652A 06652-61023 Right Tunnel Board
65/6653A 06653-61023 Right Tunnel Board
65/6654A 06654-61023 Right Tunnel Board
65/6655A 06655-61023 Right Tunnel Board
A4A3 Bottom Left Tunnel Board (same as A4A1)
A4A4 Bottom Right Tunnel Board (same as A4A2)
A4RT301 06652-60006 Thermistor assy (mounted on right hand top
side of heat sink assy)
5062-3704 Strap handle
5041-8819 Cap - strap handle, front
5041-8820 Cap- strap handle, rear
5001-6748 Front panel dress
5040-1703 Front frame
0515-0413 Screw mach M4 x 0.7 6 mm lg pan head (ref
rear panel, xfmr bracket, GPIB board)
5001-6771 Rear panel
06652-00004 Cover top
06652-00007 Bracket-transformer
06652-00008 Shroud for heat sink
06652-20001 Heat sink (ref A4 top and bottom)
06652-60001 Chassis
06652-60005 Jumper assy (ref xfmr Tl)
1400-0493 Cable tie (ref bias cable to front bracket)
1400-0528 Mount cable tie (ref front bracket)
