Agilent Technologies 654 A Series Service Manual

116 Replaceable Parts
Table 5-6. Parts List For 500 Watt 655xA & 665xA Main Chassis (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
5041-8801 Foot
0360-2191 Cover, terminal block
0361-1240 Rivet-blind (ref GPIB bracket to chassis)
0370-2862 Pushbutton (ref sense switch S610)
2110-0565 Fuseholder Cap (ref XFMR 450)
0515-0l06 Screw-mach M4 x .7 8mm lg (ref bus bar, AC
gnd, shroud to base)
0515-1655 Screw mach M4 x 0.7 12mm lg (HS rails, PCB
gnd)
0535-0031 Hex nut with lockwasher (ref fan top shroud)
0535-0082 Hex nut (shroud to base, AC gnd)
0515-1132 Screw mach M5 x 0.8 l0 mm lg (ref top cover)
0515-1105 Screw mach M3 x 0.5 10 mm lg (front frame to
chassis)
0515-0911 Screw mach M3 x 0.5 12 mm lg (fan to
shroud ,thermistor)
0515-0909 Screw mach M4 x 0.712 mm lg (HS rails, PCB
ground)
3050-0893 Washer (HS rails, GPIB, safety cover)
6651A-6655A 0160-0895 RFI strip (ref top cover)
5001-0539 Side trim strips
5040-1666 Hs rail
5040-1667 HS bumper
3050-1053 Washer fl mtlc (ref fan to shroud)
2190-0586 Washer lk hlcl (ref HS rails, PCB gnd)
2190-0646 Washer lk (ref AC gnd)
1400-0493 Cable tie (ref tunnel cables, AC bias cable)
1400-1281 Cable clip (ref tunnel, AC power cables)
1400-0611 Cable clamp (ref front panel phone cable)
0370-3238 Knobs (ref A3GI, A3G2)
5001-6740 GPIB board bracket
1510-0044 Binding post
1000-0842 Window (ref front panel display)
0590-0534 Nut self-thd (ref display to front panel)
1252-1488 Quick-disconnect mating plug for DIG CNTL
connector A2TB101
1252-3698 Quick-disconnect mating plug for external
connector AlJ640
5080-2148 Chaining cable for power supply link
5959-3317 operating Manual
9211-5869 Shipping carton
9222-0456 Bag cushioned
9222-1363 Bag static
5080-2120 Foam pad
5080-2211 Label
