Replaceable Parts 117
Table 5-7. Parts List For 500 Watt A1 Main Board for 655xA & 665xA
Reference
Desig.
Applicable Models Agilent Part No. Description
C403 65/6651A, 65/6652A 0160-5422 Capacitor .047 uF 20%
65/6653A-65/6655A Not used
C404 65/6651A, 65/6652A Not used
65/6654A, 65/6655A Not used
65/6653A 0160-6803 Capacitor .047 250V
C405,406 65/6651A 0180-4321 Capacitor 39000 uF 25V
65/6652A 0160-4264 Capacitor 18000 uF 50V
65/6653A 0180-4272 Capacitor 10000 uF 80V
65/6654A 0180-4263 Capacitor 4000 uF 125V
65/6655A 0180-4311 Capacitor 1200 uF 250V
C407 65/6651A 0180-4321 Capacitor 39000 uF 25V
65/6652A 0160-4264 Capacitor 18000 uF 50V
65/6653A 0180-4272 Capacitor l0000 uF 80V
65/6654A, 65/6655A Not used
C408,409 65/6651A 0180-4321 Capacitor 39000 uF 25V
65/6652A-65/6655A Not used
C411 65/6651A, 65/6652A 0160-5422 Capacitor .047 uF 20%
65/6653A-65/6655A Not used
C412 65/6651A, 65/6652A Not used
65/6654A, 65/6655A Not used
65/6653A 0160-6803 Capacitor .047 uF 250V
65/6652A, 65/6654A Not used
C413 65/6651A-65/6653A,
65/6655A
0160-5469 Capacitor luF l0% 50V
65/6654A 0160-5101 Capacitor 1 uF 10%
C414,415 0160-5422 Capacitor .047 uF 20%
C416 65/6651A 0180-4321 Capacitor 39000 uF 25V
65/6652A, 65/6653A 0180-3963 Capacitor 17000 uF 16V
65/6654A Not used
C417 65/6651A-65/6653A Not Used
65/6654A, 65/6655A 0180-3497 Capacitor 6800 uF 16V
C418 65/6651A-65/6653A Not Used
65/6654A 0160-0168 Capacitor .1 uF 10%
65/6655A 0160-4065 Capacitor .1 uF 10%
C450, 451 0160-4281 Capacitor 2200 pF 20%
C452 0160-4962 Capacitor 1.0 uF 20%
C501 0160-5422 Capacitor .047 uF 20%
C502,503 0160-4805 Capacitor 47 pF 5% l00V
C504 0160-5422 Capacitor .047 uF 20%
C505 65/6651A-65/6655A 0160-4129 Capacitor 1 uF 35V
C506 0160-4801 Capacitor 100 pF 5%
C507 0160-5422 Capacitor .047 uF 20%
C509 0160-5422 Capacitor .047 uF 20%
C510 0160-4801 Capacitor 100 pF 5%
C512 0160-5422 Capacitor .047 uF 20%
C513 0160-4801 Capacitor l00 pF 5%
C515 0160-5422 Capacitor .047 uF 20%
C516 0160-480l Capacitor 100 pF 5%
