Agilent Technologies 654 A Series Service Manual

118 Replaceable Parts
Table 5-7. Parts List For 500 Watt A1 Main Board for 655xA & 665xA (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
C517,518 0160-5422 Capacitor .047 uF 20%
C519 65/6651A-65/6655A 0180-4129 Capacitor 1 uF 35V
C520-522 0160-5098 Capacitor .22 uF 10%
C523 Not used
C524 0160-5422 Capacitor .047 uF 20%
C600 0160-4834 Capacitor .047 uF l0% l00V
C602 0180-3458 Capacitor 4700 uF 50V
C603 0180-3298 Capacitor 2200 uF 50V
C604,606 65/6651A-65/6655A 0180-4129 Capacitor 1 uF 35V
C605 0180-0197 Capacitor 2.2 uF 20V TA
C610 0160-5469 Capacitor 1 uF 10% 50V
C611 0160-4808 Capacitor 470 pF 5%
C612 0160-4835 Capacitor .1 uF 10% 50V
C613,614 65/6651A 0160-4835 Capacitor 0.l uF l0% 50V
65/6652A 0160-5422 Capacitor 0.047 uF 20%
65/6653A 0160-5166 Capacitor 0.015 uF 20%
65/6654A 0160-5409 Capacitor 3000 pF 5%
C615-618 0160-5422 Capacitor 0.047 uF 20%
C619 65/6651A, 65/6653A 0160-4791 Capacitor l0 pF 5% l00V
65/6652A 0160-4795 Capacitor 4.7 pF
65/6654A, 65/6655A 0160-4789 Capacitor 15 pF 5% l00V
C620 Not used
C621 0160-4821 Capacitor 1200 pF 5%
C622 65/6651A, 65/6653A 0160-4791 Capacitor 10 pF 5% l00V
65/6652A 0160-4795 Capacitor 4.7 pF
65/6654A, 65/6655A 0160-4789 Capacitor 15 pF 5% l00V
C623 65/6651A, 65/6652A 0160-4801 Capacitor l00 pF 5% l00V
65/6653A-65/6655A Not used
C624 65/6651A, 65/6652A, 0160-4788 Capacitor 18 pF 5% l00V
65/6655A
65/6653A, 65/6654A 0160-4791 Capacitor l0 PF 5% l00V
C640 0180-6827 Capacitor 0.022 uF 400V
C641 0160-0161 Capacitor 0.01 uF l0%
C642 65/6651A, 65/6652A 0160-4813 Capacitor 180 PF 5%
65/6653A, 65/6654A 0160-4803 Capacitor 68 PF 1
65/6655A 0160-4805 Capacitor 47 pF 5% l00V
C643,644 Capacitor .047 uF 20%
C645 0160-4355 Capacitor 0.01 uF 10%
C646 65/6651A, 65/6652A 0160-4805 Capacitor 47 uF
65/6652A-65/6654A Not used
C671 0160-4791 Capacitor 10 pF 5% l00V
C672 65/6651A, 65/6655A 0160-4807 Capacitor 33 pF 5% l00V (mounted on
pins)
65/6652A-65/6654A 0160-4807 Capacitor 33 pF 5% l00V (in D673 location)
C673-689 Not used
