Agilent Technologies 654 A Series Service Manual

Replaceable Parts 119
Table 5-7. Parts List For 500 Watt A1 Main Board for 655xA & 665xA (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
C690 65/6651A Not used
65/6652A 0180-2728 Capacitor 1100 uF 40V
65/6653A 0180-3382 Capacitor 440 uF 50V
65/6654A 0180-3685 Capacitor 120 uF l00V
65/6655A 0180-3653 Capacitor 56 uF 200V
C691 65/6651A-65/6653A 0160-5422 Capacitor 0.047 uF 20% 50V
65/6654A 0180-4834 Capacitor 0.047 uF 10% l00V
65/6655A 0160-0159 Capacitor 6800 pF 10%
C692,693 0160-4355 Capacitor 0.01 uF 10%
C694 0160-5410 Capacitor 3300 pF 5% 50V
65/6652A-65/6655A Not used
C700,7010160-5422Capacitor 0.047 uF 20%
C702 0160-4812 Capacitor 220 pF 5%
C703-705 0160-5422 Capacitor 0.047 uF 20%
C706 0160-4832 Capacitor 0.01 uF 10%
C707 0160-5422 Capacitor 0.047 uF 20%
C708 65/6651A, 65/6655A 0160-4832 Capacitor 0.01 uF 10%
65/6652A-65/6654A Not used
C720 65/6651A, 65/6655A 0180-4136 Capacitor 10 uF 20V
65/6652A-65/6654A 0180-0374 Capacitor 10 uF 20V
C740 0160-4831 Capacitor 4700 PF 10%
C741 0160-4801 Capacitor 100 pF 5%
C742 65/6651A, 65/6655A 0180-0197 Capacitor 2.2 uF 20V TA
65/6652A-65/6654A Not used
C770 65/6651A, 65/6655A 0180-4136 Capacitor 10 uF 20V
65/6652A-65/6654A 0180-0374 Capacitor 10 uF 20V
C771 0160-4830 Capacitor 2200 pF 10%
C772 65/6651A, 65/6655A 0180-4132 Capacitor 6.8 uF 35V
65/6652A-65/6654A 0180-0116 Capacitor 6.8 uF 35V
CR700 65/6651A-65/6653A 1884-0349 Thyristor SCR
CR701 65/6654A, 65/6655A 1884-0340 Thyristor SCR
D400 65/6651A 1901-1127 Diode pwr rect
65/6652A 1901-1333 Diode pwr rect
65/6653A-65/6655A Not used
D402 65/6651A, 65/6652A Not used
65/6653A-65/6655A 1906-0383 Diode bridge
D403 Not used
D404 65/6651A 1901-1127 Diode pwr rect
65/6652A 1901-1333 Diode pwr rect
65/6653A-65/6655A Not used
D405 65/6651A 5060-3228 Assy-HS (includes diode 1901-0987)
65/6652A, 65/6653A 1901-0987 Diode pwr rect
65/6654A, 65/6655A Not used
D406,407 65/6651A-65/6653A Not used
65/6654A, 65/6655A 1901-0719 Diode
D408 65/6651A 5060-3228 Assy-HS (includes diode 1901-0987)
65/6652A, 65/6653A 1901-0987 Diode pwr rect
65/6654A, 65/6655A Not used
C69565/6651A0180-4346Capacitor fixed 10000 uF
