96 Replaceable Parts
Table 5-4. Main Chassis Replaceable Parts for 200 Watt Models 654xA and 664xA
Reference
Desig.
Applicable
Models
Agilent Part No. Description
Al 65/6641A 06641-61030 Mother Board PCA Tested
Al 65/6642A 06642-61030 Mother Board PCA Tested
Al 65/6643A 06643-61030 Mother Board PCA Tested
A1 65/6644A 06644-61030 Mother Board PCA Tested
A1 65/6645A 06645-61030 Mother Board PCA Tested
A2 6541A-6545A 5060-3398 Isolator Board PCA Tested
A2 6641A-6645A 5060-3399 GPIB Board PCA Tested (surface mount, see Table 5-9A)
A2 6641A-6645A 5060-3317 GPIB Board PCA Tested (through-hole, see Table 5-9B)
A3 5060-3400 Front Panel Board Tested but Uninitialized
A3 6541A 06541-61001 Front Panel Board Tested & Initialized
A3 6542A 06542-61001 Front Panel Board Tested & Initialized
A3 6543A 06543-61001 Front Panel Board Tested & Initialized
A3 6544A 06544-61001 Front Panel Board Tested & Initialized
A3 6545A 06545-61001 Front Panel Board Tested & Initialized
0515-0433 Machine screw, M4 x 0.7 8 mm lg. REF XFMR bracket
0515-0374 Machine screw, M3 x 0.5 10 mm lg. REF: front frame
0515-0380 Machine screw, M4 x 0.7 l0 mm lg. REF cover, (5)
PCB,(l)GN
0515-0386 Machine screw, M5 x 0.810 mm lg. REF: 2 Cover
0515-1085 Machine screw REF TERM Cover (2)
0515-1285 Machine screw REF: Fan Mounting
0515-1384 Machine screw M5X0.8 REF: 2 Handle
2190-0016 Lock washer INTL T REF RPG Front Panel Board
2190-0585 Lock washer HLCL REF Fan mounting
2190-0586 Lock washer HLCL GPIB Connector
0380-0643 Nut GPIB Connector
2190-0646 Lock washer REF ground wire
3050-0893 Flat washer MTLC REF Isolator PCA
2950-0043 Hex nut DBL-CHAM REF RPG Front Panel Board
0535-0023 Hex nut DBL-CHAM REF Isolator PCA self thread
0590-0534 Nut self-treading REF Display to front panel
1252-1488 Quick-disconnect mating plug for DIG CNTL
connector A2TBl0l
1252-3698 Quick-disconnect mating plug for external
connector AlJ640
5080-2148 Chaining cable for power supply link
5080-2228 Label rear
5080-2248 Label instrument
6541A 06541-80001 Nameplate
6542A 06542-80001 Nameplate
6543A 06543-80001 Nameplate
6544A 06544-80001 Nameplate
6545A 06545-80001 Nameplate
6641A 06641-80001 Nameplate
6642A 06642-80001 Nameplate
6643A 06643-80001 Nameplate
6644A 06644-80001 Nameplate
6645A 06645-80001 Nameplate
0360-2191 Cover terminal block
