Replaceable Parts 97
Table 5-4. Main Chassis Replaceable Parts for 200 Watt Models 654xA and 664xA(continued)
Reference
Desig.
Applicable
Models
Agilent Part No. Description
0370-3238 Knob Ref RPG
0370-2862 Pushbutton
0380-0181 Spacer round .75-lN REF fan mounting
0380-1524 HEX standoff 8-MM REF Isolator PCA
0960-0912 Optical encoder, front panel board
l000-0842 Window
1531-0309 Clevis
5062-3974 Rack mounting kit
5062-3975 Rack mounting kit w/handles
06632-60002 Fan assembly
5001-6787 Shim Ref. XFMR MTG
5001-6788 XFMR bracket
5041-8801 Foot
65/6641A 9100-4963 XFMR power bias
65/6642A 9100-4964 XFMR power bias
65/6643A 9100-4965 XFMR power bias
65/6644A 9100-4966 XFMR power bias
65/6645A 9100-4967 XFMR power bias
5060-3364 Chassis assembly
P640 1252-3698 Connector
S00l 3101-2862 Rocker switch S00l
W1 5080-2204 AC cable assembly
W2 5080-2205 Primary cable assembly
W3 65/6642-65/6645 5080-2206 Secondary power cable
W3 65/6641A 06641-80002 Secondary power cable
W7 5080-2213 Bias cable
W8 5080-2209 GPIB power cable assembly
W9 06652-80010 6-Conductor phone cable
W10 06652-80011 6-Conductor phone cable
W19 5080-2261 Cable assembly LCD display
5001-0538 Side Trim
5001-6765 Front panel
500 1-6769 Cover
5001-6775 Plate cover, Ref. 654xA rear panel
5040-1665 Keypad
5063-3407 PCA Keypad
5040-1687 Front frame
5040-1700 Molded collar, Ref. RPG
5041-8819 Strap-Cap handle, front
5041-8820 Strap-Cap handle, rear
5061-1190 LCD display
5062-3703 HDL strap assembly
P640 1252-3698 Connector
F450 2110-0010 Fuse 5AM 250V for 120 V operation
2110-0565 Fuse holder (Ref F450)
F450 2110-0056 Fuse 6AM 250V for 100 V operation
F450 2110-0003 Fuse 3AM 250V for 220 V operation
664xA, 665xA 5959-3350 Operating Manual
654xA, 655xA 5959-3374 Operating Manual
