Agilent Technologies 86140B Series User Manual

7-10
Specifications and Regulatory Information
Specifications
Table 7-6. Sweep Specifications
Table 7-7. Pulse Mode Accuracy Specifications
Sweep
Agilent 8614xB
a
a. The 86144B and 86146B specifications are for the 50 µm internal path only.
Maximum Sweep Rate
b
b. Characteristic
40 nm/56.3 ms
Maximum Sampling Rate in
Zero Span
b
50 µs/trace point
Sweep Cycle Time
b
50 nm span, auto zero off
50 nm span, auto zero on
100 nm span
500 nm span
<180 ms
<340 ms
<400 ms
<650 ms
ADC Trigger Accuracy
b
Jitter (distributed uniformly)
Trigger delay range
<
±0.5 µs
2
µs-6.5 ms
PULSE MODE ACCURACY
Agilent 86140B, 86143B,
86144B
a
a. The 86144B and 86146B specifications are for the 50 µm internal path only.
Agilent 86142B, 86145B,
86146B
a
Agilent 86141B and
86140B Option 025,
86143B w/Opt 025
Turn On (
≥ 2 µs after rising
edge)
b
,
c
b. Characteristic
c. Starting from dark
< ± 0.2 dB < ± 0.2 dB < ± 0.2 dB
Turn Off (≥ 10 µs after falling
edge)
d
d. Characteristic for 86140B, 86141B, 86143B, 86144B, 86146B, 86140B w/Opt 025, 86143B w/Opt 025
<
± 0.2 dB <± 0.2 dB
(30 dB extinction)
< ± 0.2 dB
