26 G7200-90210 (Rev. A) MassHunter Workstation Quick Start Guide
Open an existing batch for data analysis
If the window is not already open, open the ICP- MS Data Analysis window in
either of the following ways:
• Select Main Panel from the DataAnalysis menu in the ICP- MS Top window,
or
• Click the button on the ICP- MS Top toolbar.
Tip To open an existing batch:
a Select Open Analysis File from the File menu to open the Open Batch
dialog box.
b Select the file of interest and click Open. This opens an Analysis file with
data that has been previously acquired.
c Then proceed to “Create the Data Analysis (DA) method for
Quantitative data analysis” on page 28 to create a Data Analysis
(DA) method (if a DA method was not applied at time of data
acquisition) or to modify the method, if needed (if the DA method
was already applied).
Creating a new batch for data acquisition
1 Create a new Batch Folder, which will be used to contain your data analysis
results:
a Open the New Batch Folder dialog box in either of the following ways:
• Click the New Batch Folder toolbar button , or
• Select New Batch Folder from the File menu.
b Type in a name for the new folder (you may select a different location if
desired).
c Click the Create button.
