Technical Description
Scheduled Maintenance Cards
106/140 Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L)
Unscheduled Maintenance Card No.
105
Pump type: DS102 1Ph, DS202 1Ph, DS302 1Ph, DS402 1Ph, DS402 3Ph, DS602 1Ph, DS602 3Ph
Frequency: WHEN DAMAGED Time: 30 min Machine status: S R
Type of action: REPLACEMENT
Item: ELECTRIC MOTOR AND JOINT
Figure 22
Materials required: Equipment required:
Electric motor Mechanical tools
WARNING!
Machine safety: disconnect all power lines. Hang the card “MACHINE
UNDERGOING MAINTENANCE - DO NOT POWER ON” from the main breaker
switch. When finished, remove the safety warning.
ACTION AREA
