5
Technical Description
Scheduled Maintenance Cards
124/140 Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L)
5. After applying silicone grease to the external diameter of the oil
seal, engage it on the tool and push it into its seat.
6. Reassemble by proceeding in the inverse order.
NOTE
When reassembling, replace all the gaskets stripped down.
CAUTION!
When reassembly is complete, proceed to fill the pump with oil again following
the instructions of Unscheduled Maintenance Card No. 102.
