Technical Description
Scheduled Maintenance Cards
5
Dual Stage Rotary Vane Pumps User Manual/ 87-900-937-01(L) 125/140
Unscheduled Maintenance Card No.
111
Pump type: DS102 1Ph, DS202 1Ph, DS302 1Ph, DS402 1Ph, DS402 3Ph, DS602 1Ph, DS602 3Ph
Frequency: WHEN DAMAGED
Time: 2 hours
Machine status: S R
Type of action: DISASSEMBLY
Item: FUNCTIONAL BLOCK ROTORS
Figure 36
Materials required: Equipment required:
Oil shaft seal ring
Anti-wear bushing
OR gaskets
1st stage vanes
2nd stage vanes
Gas Ballast shutter
(the above items of material are included
in the Major Maintenance kit)
Mechanical tools
ACTION AREA
To Next Page
