Agilent Technologies E3633A User Manual

Chapter 4 Remote Interface Reference
Status Reporting Commands
100
*PSC?
This command queries the power-on status clear setting. The returned parameter is
‘‘0’’ (*PSC 0) or ‘‘1’’ (*PSC 1).
*SRE <enable value>
This command enables bits in the Status Byte enable register.
*SRE?
This command queries the Status Byte Enable register. The power supply returns a
decimal value which corresponds to the binary-weighted sum of all bits set in the
enable register.
*STB?
This command queries the Status Byte summary register. The *STB? command is
similar to a serial poll but it is processed like any other instrument command. The
*STB? command returns the same result as a serial poll but the ‘‘Request Service’’
bit (bit 6) is not cleared if a serial poll has occurred.
*WAI
This command instructs the power supply to wait for all pending operations to
complete before executing any additional commands over the interface. Used only in
the triggered mode.

Agilent Technologies E3633A Specifications

General

Output Current Range	0 to 3 A
Operating Temperature Range	0 to 50 °C
Storage Temperature Range	-40 to 70 °C
Ripple and Noise (Vp-p)	Voltage: <2 mV
Current Ripple and Noise (20 Hz to 20 MHz)	<500 μA
Voltage Programming Accuracy	0.05% + 10 mV
Current Programming Accuracy	0.1% + 5 mA
Ripple and Noise (rms)	≤ 350 µV
