Chapter 3 Front-Panel Operation
Storing and Recalling Operating States
28
Storing and Recalling Operating States
You can store up to three different operating states in non-volatile memory. This also
enables you to recall the entire instrument configuration with just a few key presses
from the front panel.
The memory locations are supplied with the reset states from the factory for front-
panel operation. Refer to the description of *RST command, starting on
page 96 in
chapter 4 for more information. The following steps show you how to store and recall
an operating state.
• Front-panel operation:
1 Set up the power supply for the desired operating state.
The storage feature “remembers” output range selection, the limit value settings of
voltage and current, output on/off state, OVP and OCP on/off state, and OVP and
OCP trip levels.
2 Turn on the storage mode.
Three memory locations (numbered 1, 2 and 3) are available to store the operating
states. The operating states are stored in non-volatile memory and are remembered
when being recalled.
This message appears on the display for approximately 3 seconds.
3 Store the operating state in memory location “3”.
Turn the knob to the right to specify the memory location 3.
To cancel the store operation, let the display time-out after about 3 seconds or press
any other function key except the
key. The power supply returns to the normal
operating mode and to the function pressed.Save the operating state.
STORE 1
STORE 3
