4
The Front Panel at a Glance
1 Output1 selection Key
2 Output2 selection Key
3 Low voltage range selection Key
4 High voltage range selection Key
5 Overvoltage protection Key
6 Display limit Key
7 Resolution selection Keys
8 Voltage / Current adjust selection Key
9 Knob
10 Output On / Off Key
11 I/O Configuration Menu / Secure Key
12 View Menu / Calibrate Key
13 State Storage Menu / Local Key
14 Stored state Recall/Reset Menu
15 Tracking enabling/disabling Key
