Tracking Generator Level Flatness: E4402B, E4403B, E4404B, E4405B,
E4407B and E4408B, Option 1DN
9. Repeat steps 5 through 7 to measure the flatness at each center
frequency setting listed in Table 3-9. The ⇑ may be used to tune to
center frequencies above 500 MHz.
10.Press
System, Alignments, Auto Align, On.
Table 3-9 Tracking Generator Level Flatness Worksheet
Center Frequency Level Flatness (dB)
100 kHz
5 MHz
40 MHz
50 MHz 0 (Ref)
80 MHz
500 MHz
1000 MHz
1500 MHz
2000 MHz
2300 MHz
2500 MHz
2700 MHz
3.0 GHz
